Product Overview

Manual Mud Discharge Valve is a common pipe fitting, mainly used to remove impurities and debris from pipes and keep the pipes unobstructed.

Main Features

• Manual operation, simple and convenient to use.
• Designed for efficient removal of mud, impurities and debris in pipelines.
• Helps maintain smooth pipeline flow and prevent blockages.
• Suitable for common pipeline systems, with good adaptability.

Working Principle

1. Under normal conditions, the valve remains closed to ensure the normal transportation of fluids in the pipeline.

2. When mud, impurities or debris in the pipeline need to be discharged, the valve is manually opened by rotating the handwheel or operating the handle.

3. After the accumulated mud and impurities are fully discharged, the valve is manually closed again to restore the pipeline to its normal working state.

Structural Features

• Equipped with a manual operating component (such as a handwheel or handle) for easy opening and closing control.
• Adopts a sealed structure to prevent fluid leakage when the valve is closed, ensuring pipeline tightness.
• Has a dedicated mud discharge channel with a reasonable caliber, facilitating smooth discharge of mud and impurities.
• The valve body is made of durable materials (e.g., cast iron, stainless steel) to withstand pipeline pressure and resist corrosion.

Maintenance

• Check hydraulic oil level annually
• Test closing time every 6 months
• Inspect disc and seat for wear during system shutdowns
• Lubricate adjustment mechanism yearly
• Verify proper operation after system pressure changes
