Product Overview

The Pneumatic Soft Seal Flange Butterfly Valve features a high-performance elastic sealing ring with flange connection design, equipped with pneumatic actuators. It offers quick operation, reliable sealing, and easy operation. Widely used in pipeline control for gas and liquid media across water treatment, chemical, food, pharmaceutical and other industries.

Product Features

• Pneumatic actuator– Fast response speed, enables remote control and automated operation
• Soft seal design– EPDM, NBR and other elastic materials achieve zero leakage
• Flange connection– Easy installation, reliable connection, compliant with GB, ANSI standards
• Bidirectional sealing– Excellent sealing performance in both flow directions
• Low flow resistance design– Minimal flow resistance when fully open, significant energy saving
• Multiple control options– Can be equipped with solenoid valves, positioners, limit switches and other accessories
• Easy maintenance– Simple structure, convenient repair and replacement

Technical Specifications

Working Principle

The Pneumatic Soft Seal Flange Butterfly Valve operates by using a pneumatic actuator to rotate the valve stem, which drives the disc to make a 90° rotation for opening and closing. When the disc is parallel to the pipeline axis, the valve is fully open; when perpendicular, the valve is fully closed. The elastic sealing ring maintains tight contact with the disc edge, ensuring zero leakage when closed. The pneumatic actuator is driven by compressed air, enabling fast response and precise control.

Structural Features

• Centerline design– Compact structure with low operating torque
• Multi-layer sealing system– Ensures tight sealing performance
• Blow-out proof stem– Safety design prevents accidental stem ejection
• Adjustable limit device– Precisely controls opening position
• Manual operation device– Optional manual override for operation during power failure

Application Fields

• Water treatment industry: Water supply and drainage systems, wastewater treatment
• Chemical industry: Various chemical media transportation
• Food and pharmaceutical: Sanitary pipeline systems
• HVAC: Cold and hot water circulation systems
• Power industry: Cooling water systems
• Petrochemical: Oil and gas transmission pipelines

Installation & Maintenance

Installation Requirements

• Clean pipelines before installation to prevent damage to sealing surfaces
• Install valves in easily accessible locations for operation and maintenance
• Tighten flange connection bolts evenly in diagonal sequence
• Ensure medium flow direction matches the arrow on valve body
• Install air filter regulator to ensure clean and dry air supply

Maintenance

• Regularly check valve sealing performance and address any leaks promptly
• Maintain clean and dry air supply, regularly drain accumulated water in pneumatic actuators
• Operate valves periodically when not in use to prevent seizing
• Keep valve stems clean and lubricate regularly
• Use original manufacturer parts when replacing seals to ensure performance
