The BFG7M43HR Pipe Force Check Valve is a high-performance, spring-assisted silent check valve designed for industrial piping systems.
The BFG7M43HR Pipe Force Check Valve is a high-performance, spring-assisted silent check valve designed for industrial piping systems. It features a unique pipe force design that minimizes pressure drop while preventing backflow, with superior sealing performance and durability for demanding applications.
| Parameter | Specification |
|---|---|
| Nominal Diameter | DN50～DN600 (2″～24″) |
| Nominal Pressure | PN10～PN40 (Class 150～300) |
| Temperature Range | -20℃～150℃ (standard), up to 400℃ (high temp version) |
| Cracking Pressure | 0.05～0.1MPa (adjustable) |
| Flow Direction | Horizontal or vertical (flow upward) |
| Connection Types | Flanged (RF, RTJ), Wafer, Lug |
| Body Material | Ductile Iron, Carbon Steel, Stainless Steel |
| Disc Material | Stainless Steel (304/316) with NBR/EPDM/FKM sealing |
| Spring Material | Stainless Steel 316 |
| Test Standards | API 598, EN 12266, ISO 5208 |
The BFG7M43HR utilizes a spring-assisted disc that opens with forward flow and closes immediately when flow stops or reverses. The spring force ensures positive closure independent of gravity or mounting position. The pipe force design optimizes fluid dynamics to maintain high flow capacity while providing reliable backflow prevention. The resilient seat provides bubble-tight sealing even at low pressures.
